All factory refurbished amplifiers still have a limited warranty against manufacturer's defects in materials and / or workmanship for a period of 30 days from the date of delivery. Amplifiers are not in the original packaging and may be missing some accessories. Amplifiers may also have slight cosmetic blemishes.
Trinity Audio Solutions presents its new 8-channel amplifier, turn your multiple amplifier set up into just one. This 8 channel amplifier is split into two different power outputs. Channel 1-4 does 130 watts per channel at 2 ohms. 5-8 channel does 250 watts per channel at 2 ohms. This way you can run your tweeter and mid ranges off the first 4 channels and your mid woofers and small sub stage off of the last 4 channels. Needless to say this amp is a solution to a lot of set ups you want to run off a singular amp. If your looking to do a large set up then make sure to match this amp with our numerous other options of amplifiers to make the perfect set up for your build.
| Specifications |
| Channel 1-4 RMS Output @ 2ohms | 130Wx4ch |
| Channel 5-9 RMS Output @ 2ohms | 250Wx4ch |
| Channel 1-4 RMS Output @ 4ohms | 80Wx4ch |
| Channel 5-9 RMS Output @ 4ohms | 150Wx4ch |
| Channel 1-4 Bridged Output @ 4ohms | 270Wx2ch |
| Channel 5-8 Bridged Output @ 4ohms | 500Wx2ch |
| THD | <0.2% |
| Frequency Response (-3dB) Channel 1-4 | 50Hz - 30KHz |
| Frequency Response (-3dB) Channel 5-8 | 10Hz - 30KHz |
| Signal To Noise Ratio | >94dB |
| Sensitivity | 0.3V - 8.2V |
| Power/ Ground Gauge Wire | 4 Gauge |
| Dimensions | 11"x7.52"x2.48" |
